Rated current :
1.0AMPContact Resistance :
20mΩ MaxWithstand Voltage :
500VAC/MinuteInsulation Resistance :
1000mMinOperation Tempererature :
-40~105℃Contact Material :
Copper AlloyContact Plating :
GoldInsulating material :
UL94V-0Standard :
PA6TorLCP+30%GFPackage :
Tube/PE Bag (standard)Delivery time :
7-10 daysEnvironmental protection :
ROHSThe Denentech 2.0mm pogo pin connector consists of plunger, pin tubes, and springs. It adopts high quality brass and thermostability plastic in line with international standards to establish a safe and highly reliable connection.
The diverse structural design of the 2.0mm pogo pin connector, stable contact area, various plating thicknesses, and fully automated production ensure longer connection and service life of the pogo pin.
Denentech SMT pogo pin connectors support highly customized designs to meet specific stroke, height, electrical and other performance requirements. Moreover, the unlimited molding design can create many different shapes and styles for specific applications, and can be widely used in various fields of multiple industries.
Denentech 2.00MM H1.27MM triple row female right angle SMYconcave pogo pin connector
Denentech pogo pin 2.00MM pogo pin H2.5 triple row female 180° SMT concave connector
Denentech gold plated 2.00MM H2.5MM triple row female straight concave pogo pin connector
Denentech customized 2.00mm pitch H4.0mm triple row female solder pogo pin connector
Denentech high quality 2.0MM H2.5MM triple row male straight pogo pinconnector
Denentech gold plated 2.0MM pogo pin H2.5MM solder triple row male
Denentech good quality 2.0MM H4.0MM triple row male right angle pogo pin connector
