Rated current :
1.0AMPContact Resistance :
20mΩ MaxWithstand Voltage :
500VAC/MinuteInsulation Resistance :
1000mMinOperation Tempererature :
-40~105℃Contact Material :
Copper AlloyContact Plating :
GoldInsulating material :
UL94V-0Standard :
PA6TorLCP+30%GFPackage :
Tube/PE Bag (standard)Delivery time :
7-10 daysEnvironmental protection :
ROHSThe Denentech 2.54mm male pogo pin connector consists of plunger, pin tubes, and springs. It adopts high quality brass and thermostability plastic in line with international standards to establish a safe and highly reliable connection.
The diverse structural design of the 2.54mm pogo pin connector, stable contact area, various plating thicknesses, and fully automated production ensure longer connection and service life of the pogo pin.
Denentech pogo pin connectors support highly customized designs to meet specific stroke, height, electrical and other performance requirements. Moreover, the unlimited molding design can create many different shapes and styles for specific applications, and can be widely used in various fields of multiple industries.
Denentech 2.54MM pogo pin H4.0MM single row female right angleSMT concave spring loaded pogo pin connector
Denentech 2.54MM pogo pin H1.27MM single row female right angle concave spring loaded pogo pin connector
Denentech 2.54mm pitch H2.5 single row female straight SMT pogo pin connector
Denentech 2.54mm pitch H1.27 single row female straight DIP concave pogo pin connector
Denentech 2.54mm pitch H2.5 solder single row female pogo pin connector
Denentech 2.54MM pogo pin H2.5MM single row male right angle 4 pin pogo pin test probe connector with peg
Denentech 2.54MM pogo pin H2.5MM solder single row male spring test probe pogo pin connector
Denentech Factory direct sales 2.54mm pitch H2.5 single row male right angle SMT pogo pin connector
Denentech 2.54MM pogo pin H4.0MM single row male straight SMT spring loaded pogo pin charger connector
