Rated current :
3.0 AMPContact Resistance :
20mΩ MaxWithstand Voltage :
500VAC/MinuteInsulation Resistance :
1000mMinOperation Tempererature :
-40~105℃Contact Material :
Copper AlloyContact Plating :
Tin-PlateInsulating material :
UL94V-0Standard :
PA6TorLCP+30%GFPackage :
PE Bag/Blister Tray/Tape&ReelDelivery time :
7-10 daysEnvironmental protection :
ROHSDenentech wafer connectors are made of high - quality copper materials that meetinternational standards, They have high hardness, are not easily deformed, havegood electrical conductivity and corrosion resistance, and can provide reliableelectrical connections.
The terminals of Denentech 2.5mm wafer connectors are surface - plated with tin throughelectroplating treatment, showing high stability during long - term use.
Denentech wafer connectors adopt fully - automated production and ultra - thinstructure design, achieving more connections in limited space and having a widerrange of applications.
