Denentech 2.54mm pin header single row dual plastic straight 2.54mm pin header Single row double plastic gold-plate

Serial Code : DN-PH2541ST Product Code : P525-XXSG02STXXX

Rated current :

3AMP

Contact Resistance :

20mΩ Max

Withstand Voltage :

500VAC/Minute

Insulation Resistance :

1000mMin

Operation Tempererature :

-40~105℃

Contact Material :

Copper Alloy

Contact Plating :

Gold Or Nickel-Plated

Insulating material :

UL94V-0

Standard :

PA6TorLCP+30%GF

Package :

Tube/PE Bag/Blister Tray (standard)

Delivery time :

7-10 days

Environmental protection :

ROHS
Product informatrion
Product detailsFeaturesDrawingAccessory productsRelated productsKnowledgeRelated videosContact us

High quality raw materials

Denentech connector is made of high-quality brass with international standards, which has high hardness, is not easy to deform, has faster signal current transmission speed and lower signal loss rate.

High quality raw materials
 Electroplating process

Electroplating process

The surface of Denentech2.54-pitch needle arrangement is treated by multi-layer electroplating to ensure that the product passes ROHS strict verification and 24-hour salt spray test.

Excellent quality

Denentech adopts fully automatic production of 2.54-pitch needle arrangement, automatic inspection procedures+sampling inspection by quality inspectors+advanced inspection equipment to ensure excellent product quality!

Excellent quality
Product name

2.54mm Pin Header Single Row Board Spacer Straigh DIP

pitch

2.54mm

pin spec

0.64*0.64mm

Plastic height

H2.5mm

Rated current

3A

Row number

single row

connection type

Straight DIP

Pin number

1-40Pin

Pin material

brass

Surface treatment

Gold Flash

Plastic materials

PA66, PA46, PBT, PA6T, PA9T, PPS, LCP, etc.

Pin length

Standard: 11.6mm (length can be customized)

Application

consumer electronics, automotive electronics, industrial automation, communication electronics, etc

Product features

high temperature resistance/flame retardant
